- Information
11kv-33kv Ht Vcb Panels Description
11kv-33kv Ht Vcb PanelsRated Current
1250A
Cooling System
Natural Air Ventilation
Cover Material
Powder-Coated Steel
Base Material
Steel
Panel Type
Vacuum Circuit Breaker Panels
Connectivity Type
Hardwired
Features
Compact Design High Safety Standards Reliable Performance
Cabinet Material
Steel
Protection Level
High Voltage Protection
Thickness
2mm-3mm
Operating Voltage
11kV-33kV
Control System
Electrical Control
Current Rating
Up to 1250A
Way
Single and Multiple Ways
Components
Vacuum Circuit Breaker Current Transformers Voltage Transformers Control and Indication Modules
Protection Class
Class 1
Rated Operation Voltage
11kV-33kV
Rated Insulation Voltage
Up to 36kV
Product Type
HT Panels
Material
Steel
Surface Finish
Powder-Coated Finish
Standard
IEC 62271-100
Surface Color
Gray
Rated Voltage
11kV-33kV
Frequency (MHz)
50Hz
Maximum Output Current
1250A
Dimension (L*W*H)
Customizable
Warranty
1 Year
Application
Power Distribution
IP Rating
IP4X
Display Type
Analog and Digital Indicators
