ABB REF615E E HBFCACABNCA1BNN1XE RELAY

ABB REF615E E HBFCACABNCA1BNN1XE RELAY Description

ABB REF615E E HBFCACABNCA1BNN1XE RELAYABB REF615E E HBFCACABNCA1BNN1XE RELAY Specification
Ambient Temperature
25C to +55C
Working Temperature
25C to +70C (storage)
Dielectiric Strength
Withstands 2kV AC for 1min
Power Consumption
Max 10 W
Protect Feature
Overcurrent Earth Fault Voltage Frequency protection
Product Type
Feeder Protection Relay
Insulation Resistance
Min 100 M at 500 V DC
Theory
Electromechanical/Intelligent Digital Processing
Usage
Feeder protection in medium voltage networks
Operate Time
Approx. 100ms (estimated depending on application)
Terminal Type
Screw
Rated Voltage
100/110 V AC
Supply Terminal
Screw terminal
Size
Moderate
Color
Silver/White
Dimension (L*W*H)
100 mm x 230 mm x 230 mm
Weight
2.5 kg
Warranty
1 year


About ABB REF615E E HBFCACABNCA1BNN1XE RELAY
ABB REF615E_E HBFCACABNCA1BNN1XE RELAY

REF615 is a dedicatedfeeder protection and control relayfor protection, control, measurement and supervision of overhead lines and cable feeders in utility and industrial power distribution systems, including radial, looped and meshed distribution networks, with or without distributed power generation.
