ABB REU610CVVHCNR RELAY

ABB REU610CVVHCNR RELAY Description

ABB REU610CVVHCNR RELAY
ABB REU610CVVHCNR RELAY Specification
Protect Feature
Overcurrent, earth fault protection
Power Consumption
Max. 10 W
Coil Voltage
110V DC
Contact Material
Silver alloy
Dielectiric Strength
2 kV for 1 minute
Mechanical Life
10 million operations
Contact Form
SPDT
Working Temperature
-10C to +55C
Contact Resistance
50 m
Coil Power
10 W
Ambient Temperature
-25C to +55C
Product Type
Protection Relay
Insulation Resistance
>100 M at 500 V DC
Theory
Electromechanical
Usage
Protection and control of electrical power systems
Contact Load
5A / 250V AC
Operate Time
<45 ms
Terminal Type
Screw terminal
Rated Voltage
110V DC
Supply Terminal
Auxiliary and main terminals
Size
Standard compact
Color
Grey
Dimension (L*W*H)
150 mm x 125 mm x 238 mm
Weight
Approx. 2.1 kg


About ABB REU610CVVHCNR RELAY
ABB REU610CVVHCNR RELAY

REU610 is a voltage protection relay for system voltageprotection, measuring and supervising in utility and industrialpower systems. REU610 is a member of ABBs Relionprotection and control product family and part of its 610product series. The 610 series includes protection relays forfeeder protection, motor protection and general system voltagesupervision. The plug-in design of the 610 series protectionrelays facilitates the commissioning of the switchgear andenables fast and safe insertion and withdrawal of relay plug-inunits.The protection relay is primarily designed for the overvoltageprotection of power system components, such as busbars,feeders, power transformers and capacitor batteries. It is alsoused for the general power system earth-fault supervision.Further, the protection relay can be used for undervoltageprotection of motors and overvoltage protection of capacitorbatteries, for initialization of automatic busbar changeover anddisconnecting small power units from the network in case of amajor network disturbance. The 610 series protection relaysare suitable for employment in marine and offshoreenvironments.The numerical voltage protection relays of the 610 seriessupport a wide range of standard communication protocols,among them the IEC 61850, IEC 60870-5-103, DNP3, Modbus,Profibus, LON and SPA communication protocols.
