CNC lathe Colchester Tornado 220M Description
CNC lathe
Colchester Tornado 220M
Description
MAKE COLCHESTER
MODEL TORNADO 220M
CONTROL FANUC 21i-TB
YEAR 2001
SWING OVER BED 510.0 mm
MAX. TURNING DIAMETER 260.0 mm
MAX. TURNING LENGTH 540.0 mm
TRAVELS X AXIS: 235 mm Y AXIS: 540 mm
TURRET 12 STATION, VDI TURRET
SPINDLE SPEED 4,000 RPM
SPINDLE BORE 80 mm
SPINDLE NOSE A2-6
Bwjbxjwl A Hwj Ri Tq Ijp
SPINDLE MOTOR 22 kW
RAPID FEED RATES X - 25 m/min Z - 30 m/min
BAR CAPACITY 66 mm
See picture for further data
Machine is fully functional
