CNC lathe EMAG VLC 100 P

Working area
Chuck diameter 160 mm
Weight max. 86* kg
Swing diameter 200 mm
X-travel (working stroke) 380 mm
Z-travel 660 mm
Loading time (depending on clamping device) 1 – 2 sec.

Main spindle 2 number
Spindle flange according to DIN 55026 5 size
Spindle bearing – Ø front 80 mm
Maximum speed 6000 rpm.

Main drive, see description 2 number

Feed drive
Rapid traverse speed, X 60 m/min.
Rapid traverse speed, Z 60 m/min.
Feed force in X/Z 3.75 / 7.5 kN
Ball screw diameter in X / Z 32 / 40 mm
Disc turret, see description
Electronic equipment in accordance with VDE 0113
Operating voltage 400 V
Control voltage direct current 24 V
Bwsbovz S Sijx Ri Tmqop
-alternating current 230 V
Frequency 50 Hz
Connection value
Connection power without Lt 36 kW
Connection power with Lt 39 kW
Rated current 64 A
Supply line fuse 80 A
Dimensions and weight
Depth 2800 mm
Depth including chip conveyor 4350 mm
Width 1200 mm
Width with automation 1600 mm
Height 2500 (2800) mm
Weight approx. 7000 kg
