- 4-jaw faceplate Ø 550 mm
- 3-jaw lathe chuck Ø 310 mm incl. 4 sets of hard base jaws, 1 set of hard top jaws, 8 sets of soft top jaws
- Fixed steady rest
- rotating center point MK5
- Mulifix B quick-change holder incl. 10 tool holders
- Switch-on time 32582 h
- Year of manufacture 1997
- incl. operating instructions and technical documentation

Technical data:

Working range:
- Tip width: 1000 mm
- Center height: 280 mm
- Circumferential diameter over bed: 570 mm
- Circumferential diameter over facing slide: 340 mm
- Bed width: 350 mm
- Movement of the facing slide: 340 mm
- Movement of the top support: 140 mm
- Slide gate length: 700 mm
- Slide width: 220 mm
- Bed slide guide length: 560 mm
- Turning tool cross-section (height/width): 32 x 25 mm
Turning spindle:
- Spindle head according to DIN 55027: size 8
- Spindle diameter in front bearing: 100 mm
- Spindle bore: 66 mm
- Inner taper of the main spindle: metr. 70
Main drive:
- Drive power 60% / 100% ED: 15 / 11 kW
- Max. Torque at the turning spindle: 1600 Nm
- Total speed range: 1 - 2500 rpm
- Speed range gear stage I: 1 - 625 rpm
- Speed range gear stage II: 4 - 2500 rpm
Feed drive:
- Type: Three-phase servo drives
- Feed range longitudinal and planar: 0 - 10 mm/rev
- Feed force longitudinal: 9000 N
- Feed force planar: 7000 N
- Input speed longitudinal/plane: 7 / 3.5 m/min
