FANUC 32i A CNC Control
Spindle Hours: 8,541h
Technical Details
Travel over Slide: 900 mm
Turning Length: 3,200 mm
Travel over Bed: 1,030 mm
Standard Turning Diameter: 750 mm
Dcebxewqpn Es Ri Tq Isi
Spindle Bore: 110 mm
X Stroke: 471 mm
Z Stroke: 2,100 mm
Rapid Feed - Longitudinal/Transverse: 15/20 m/min
Spindle Speed: 3,000 rpm
Spindle Motor: 45 kW
Turret: 12/6 BMT 85
Electric Motor: Tools: 7.5/5.7 kW
Driven Speed: Tools: 3,000 rpm
Total Power Requirement: 62.2 kVA
Machine Weight: Approx. 22 t
Dimensions: 7,357 x 2,710 x 2590 mm
Accessories:
12-position turret for driven tools
Hydraulic tailstock
Sandvik Capto C6 tool holders – 4 pcs
Hydraulic chuck Ø630 mm SMW Autoblock
Hydraulic steady rest (min. 110 mm, max. 530 mm)
