FUJI GALAXY - FD-11 - GENERATORS - IQ9500 CUBE Description
FUJI GALAXY - FD-11 - GENERATORS - IQ9500 CUBE
Description
Standby power 12kVA/9.5kW
Power factor cos ? 0.8
Full load 11.5kVA/9kW
Voltage 230/400V
Generator power 12/8.3 V/A
Number of phases 3
Type of self-exciting alternator
Electric start
Iebx Ri Tji Nxhdeqlsic
Noise level at 7m 75dB
Tank capacity 30 L
Electrical box dimensions (D x L)) 245 x 130 mm
Oil type CC or CD
Air cooling
Frequency 50Hz
Engine speed 3000 rpm
Key/push start
Working temperature - 15°C- 40°C
Storage temperature - 25°C - 45°C
Engine Model 1102F
Engine type air-cooled single-cylinder diesel engine
Cylinder diameter and length 102 x 88 mm
Engine capacity 718 cc
Fuel diesel
2L oil tank capacity
Injection type direct injection
Tank capacity 30 L
IP rating IP 44 on front panel
EURO V emission standard
Overall dimensions (length x width x height) 1120 x 640 x 900 mm
Weight 240 kg
