Fliegl DTS S 300 Parab/Hydr. Description
Fliegl DTS S 300 Parab/Hydr.Description
Further information
Chassis low loader trailer
Welded steel construction
Turntable with powerful ball bearing slewing ring
Folding rear support
2 wheel chocks with holder
Aluminum side bumpers
Rear spray flaps across the entire width
Half-shell mudguard 1st axle with anti-spray flapsAnti-spray flaps behind 2nd and 3rd axle
1 plastic tool box, with shelf, w=620/h=360/t=440 mm, lockable with a padlock.
Extensions extendable to 3,000 mm
Storage compartment for wooden planks in the middle of the loading area
Wooden planks 70 mm for widening to 3000 mm
Low loader lashing eyes (40 lashing options)
1 pair of lashing cut-outs in the front side member on offset, 10 tons each
4 pairs of lashing holes in the outer frame, 5 tons each (lashing strap attachment) 7 pairs of lashing mushrooms at the top and sides of the outer frame, 10 tons each
1 x front on offset
6 x in the drop deck
First lashing eye 250 mm from the front and last max. 250 mm from the rear, distance between lashing eyes not greater than 1100 mm
5 pairs of stake pockets embedded in the outer frame, inside 70 x 40 mm, (can be converted to 5 to. ring lashing eyes)
2 additional pairs of hinged lashing eyes, 10 tons each
1 x on offset (protrudes)
1 x embedded in the floor behind the last axle
Trailer drawbar Turntable
Drawbar with tested 40 mm drawbar eye
Axles + suspension
Drum brake axles
Parabolic suspension with maintenance-free steel-rubber bearings and mechanical axle load compensation (rocker compensation)
Wheels and tires
235 / 75 R 17,5
at the manufacturer's choice
Twin steel rims, factory silver
Brake system
2-line compressed air brake system
Cpobx Tfzbsi Ri Dljast
Spring-applied parking brake
2 non-interchangeable coupling heads at the front, with connecting cables to the motor vehicle,
