Fliegl ZPS 200 K Jumbo Z Description
Fliegl ZPS 200 K Jumbo ZDescription
Further information
Cjbxsi Ri Nuo Tfzbaopt
Chassis Turntable Disposal
Fine-grained steel welded construction
Container locking system:
- 2 pairs of locking hooks embedded in the floor
- Pneumatic actuation
The container locking mechanism is a 2-point design, acting from the inside, and locking of roll-off containers with an inner web is not possible (for transporting roll-off containers with a sub-frame in accordance with DIN 30722)
Note! At the start of the roller recess at the front, the container must be pushed on completely flat!
Longitudinal guide rails can be moved sideways and removed, rails approx. 115 mm high
Turntable with strong ball bearing slewing ring
8 pairs of lashing mushrooms at the top and sides of the outer frame, 5 tons each
7 pairs of stake pockets embedded in the outer frame, inside 70 x 40 mm, (can be converted to 5 to. ring lashing eyes, not included)
2 wheel chocks with holder
Aluminum side bumpers
Steel underride guard
Quarter-shell mudguards according to EG
with anti-spray flaps according to EG
Towing equipment Trailer turntable
Drawbar with tested 40 mm drawbar eye
Axles + suspension
SAF drum brake axles
