Gantry Milling Torresmill 5-axis Description
TECHNICAL SPECIFICATIONS
X-axis: 13.000 mm
Y-axis: 4.500 mm
Z-axis: 1.000 mm
Distance between columns: 6.500 mm
C-axis: 190º
A-axis: 110º
Positioning speed XYZ: 15.000 mm/min.
Positioning speed AC: 10 tpm
CNC Controller: Siemens 840D
Spindle nose: HSK A63
Spindle speed: 30.000 rpm
Spindle power: 20 kW
Toolchanger: 20 Pockets
Torrestool tables: 16x
X-axis: 11.500 mm
Y-axis: 3.500 mm
Z-axis: 750 mm
Country of origin: Spain
Machine size LxWxH: 19.000 x 11.000 x 6770 mm
Machine weight: 70.000 kg
The Torresmill Gantry is a 5-axis CNC milling and drilling machine, specially designed to work on aeronautical materials (Composite, Aluminum, Titanium, Steel, ...).
