KAWASAKI - HMB125 - Staffa Radial Piston Motors Description
KAWASAKI - HMB125 - Staffa Radial Piston Motors
Brand: KAWASAKI
Model Number: HMB125
Part Name: Staffa Radial Piston Motors
Type: Fixed Displacement Radial Piston Hydraulic Motor
Model: HMB125
Displacement: 1,975 cc/rev
Continuous Torque Output: ~4,900 Nm
Peak Torque Output: ~6,800 Nm
Rated Power Output: ~47 kW at 130 rpm
Maximum Speed: 140 rpm
Low-Speed Capability: Delivers high torque with smooth operation at near-zero speeds
Operating Pressure:
Continuous: 250 bar
Peak: 315 bar
Rotation: Bi-directional
Mounting: SAE or ISO flange options
Shaft Options: Keyed or splined (per application)
Hydraulic Fluid: Mineral-based oils (ISO VG32–68 recommended)
Filtration Requirement: ISO 4406 18/14 or better
Operating Temperature Range: -20°C to +80°C
Approximate Weight: 115–130 kg
The Kawasaki is a high-performance radial piston hydraulic motor designed to deliver exceptional torque and efficiency under demanding marine conditions. Part of the renowned Staffa HPCe series, this unit is optimized for shipboard hydraulic systems requiring reliable low-speed, high-torque performance.
Its electronically managed displacement system offers enhanced control, improved energy efficiency, and reduced operating costs. Engineered for precision and durability, it is ideal for applications such as winches, cranes, and propulsion support in both commercial and offshore vessels. Compact, robust, and low-maintenance, this unit stands up to harsh environments with ease.
Special Features:
Electronically controlled variable displacement
Smooth low-speed performance with high starting torque
Built-in speed and pressure feedback capabilities
Ideal for demanding shipboard hydraulic operations
Designed for marine winches, cranes, and deck equipment
