KAWASAKI - HMHDB150 - Staffa Radial Piston Motors Description
KAWASAKI - HMHDB150 - Staffa Radial Piston Motors
Brand: KAWASAKI
Model Number: HMHDB150
Part Name: Staffa Radial Piston Motors
Type: Variable Displacement Radial Piston Hydraulic Motor
Model: HMHDB150
Displacement Range:
Minimum: ~1,225 cc/rev
Maximum: ~2,445 cc/rev
Torque Output:
Continuous: ~6,100 Nm
Peak: ~8,500 Nm
Rated Power Output: ~54 kW at 130 rpm (full displacement)
Maximum Speed: 120 rpm (at max displacement)
Control: 2-speed displacement change (hydraulic control with mechanical feedback)
Operating Pressure:
Continuous: 250 bar
Peak: 315 bar
Rotation: Bi-directional
Mounting: SAE or ISO flange
Shaft Options: Keyed or splined (per application)
Hydraulic Fluid: Mineral oil-based (ISO VG32–68 recommended)
Filtration Requirement: ISO 4406 18/14 or better
Operating Temperature: -20°C to +80°C
Approximate Weight: 160–180 kg
?? Key Features
? Variable displacement for flexible speed and torque control
? High starting torque and smooth low-speed operation
? Rugged construction for continuous heavy-duty marine and industrial use
? Long service life with low maintenance
? Proven in harsh offshore and deck machinery environments
The Kawasaki is a high-performance radial piston hydraulic motor designed to deliver exceptional torque and efficiency under demanding marine conditions. Part of the renowned Staffa HPCe series, this unit is optimized for shipboard hydraulic systems requiring reliable low-speed, high-torque performance.
Its electronically managed displacement system offers enhanced control, improved energy efficiency, and reduced operating costs. Engineered for precision and durability, it is ideal for applications such as winches, cranes, and propulsion support in both commercial and offshore vessels. Compact, robust, and low-maintenance, this unit stands up to harsh environments with ease.
Special Features:
Electronically controlled variable displacement
Smooth low-speed performance with high starting torque
Built-in speed and pressure feedback capabilities
Ideal for demanding shipboard hydraulic operations
Designed for marine winches, cranes, and deck equipment
