LATH MACHINE - MULTUS B300II Description
LATH MACHINE - MULTUS B300II
Description
OSP-P300SA control system with LCD screen
Max. turning diameter 630 mm
Max. turning length 900 mm
X travel 580 mm (+480 / -20 mm)
Y travel 160 mm (+80 / -80 mm)
Z travel 935 mm
Spindle end A2-8
Spindle bore D80 mm
Main spindle speed 50 - 5000 rpm
C axis 360° (0.001 degrees)
B axis 225° (-30° / +195°; 0.001° increment)
Power of driven tools (5 min/cont.) VAC 11/7.5 kW
Milling spindle speed 50-6,000 rpm
Milling spindle torque (5 min/cont.) 65.7 / 44.8 Nm
HAS-A63 chuck
Number of tools: 40
Motor: 15/11 kW
Feed range: 0.001 – 1,000 mm/rev
Rapid traverse (X) 40 m/min
Rapid traverse (Z) 40 m/min
Rapid traverse (Y) 26 m/min
Tailstock travel: 1,000 mm
Tailstock taper: MT5
Power requirement:
Dimensions (L x W x H) = 4,035 x 2,257 x 2,587 mm
Weight: 10,000 kg
Features, accessories
- Internal coolant supply: 20 bar
- Kitagawa B-212A8 12" chuck
- NC tailstock
- B-axis indexing in 0.001 degrees
Lobxewrr Nhs Ri Tpvsac
- Coolant supply through the milling spindle
- Dual foot pedal
- Y-axis travel: 160 mm (+80 / -80 mm)
- Hydraulic Device
- Thermo-Friendly Concept - H1 TAS-S and TAS-C
- CAS - Collision Avoidance System
- *10 dB Coordinate Measurement (1 set)
- Control Software:
* Coordinate Transformation (1 set)
* Profile Generation (1 set)
* Coordinate Calculation (1 set)
* Coordinate Change, Rotation, and Copy (1 set)
* Realistic 3D Simulation (1 set)
* Cycle Time Monitoring (1 set)
* Load Monitoring (Main Spindle, Slide) (1 set)
* Program Run Monitoring (1 set)
* 2-Color Signal Lamps (1 set)
Chip conveyor
Coolant system
Machine feet
Documentation
