LATH MACHINE - TNL 18-7 Description
LATH MACHINE - TNL 18-7
Description
Control: Traub TX 8i-s
Workpiece length, max.: approx. 200 mm
Workpiece diameter, max.: 20 mm
Main Spindle:
Speed: 12,000 rpm
Power: 5.5 kW
Spindle passage: 18 mm
Measurement system resolution Z: 0.001 mm
Counter Spindle with Tool Turret:
Ljbx Riewucqzo Tpveac
Speed: 12,000 rpm
Power: 3.4 kW
Workpiece Ø, max.: 21 mm
Workpiece clamping depth, max.: 180 mm
Clamping pressure, max.: 30 bar
Upper Tool Turret:
8 stations
Tool holder: Traub Ø 45
Traverse path X/Y/Z-axis: 120//-25/+40//250 mm
Rapid traverse X/Y/Z-axis: 20/20/40 m/min
Resolution X/Y/Z-axis: 0.0005/0.0005/0.001 mm
Lower Tool Turret:
7 stations + counter spindle
Tool holder: Traub Ø 45
Traverse path X/Y/Z-axis: 120//-20/+40//250 mm
Rapid traverse X/Y/Z-axis: 20/20/40 m/min
Resolution X/Y/Z-axis: 0.0005/0.0005/0.001 mm
Workpiece length, max.: approx. 200 mm
Workpiece diameter, max.: 20 mm
Main Spindle:
Speed: 12,000 rpm
Power: 5.5 kW
Spindle passage: 18 mm
Measurement system resolution Z: 0.001 mm
Counter Spindle with Tool Turret:
Ljbx Riewucqzo Tpveac
Speed: 12,000 rpm
Power: 3.4 kW
Workpiece Ø, max.: 21 mm
Workpiece clamping depth, max.: 180 mm
Clamping pressure, max.: 30 bar
Upper Tool Turret:
8 stations
Tool holder: Traub Ø 45
Traverse path X/Y/Z-axis: 120//-25/+40//250 mm
Rapid traverse X/Y/Z-axis: 20/20/40 m/min
Resolution X/Y/Z-axis: 0.0005/0.0005/0.001 mm
Lower Tool Turret:
7 stations + counter spindle
Tool holder: Traub Ø 45
Traverse path X/Y/Z-axis: 120//-20/+40//250 mm
Rapid traverse X/Y/Z-axis: 20/20/40 m/min
Resolution X/Y/Z-axis: 0.0005/0.0005/0.001 mm
