MPCB (MOTOR PROTACTION CIRCUIT BREAKER)

MPCB (MOTOR PROTACTION CIRCUIT BREAKER) Description

MPCB (MOTOR PROTACTION CIRCUIT BREAKER)MPCB (MOTOR PROTACTION CIRCUIT BREAKER) Specification
Protect Feature
Short Circuit, Overload, Phase Failure
Dielectiric Strength
2500V AC for 1 min
Coil Voltage
Not Applicable (Manual Operation)
Mechanical Life
100,000 operations
Contact Resistance
<50 m?
Ambient Temperature
-20°C to +60°C
Contact Material
Silver Alloy
Working Temperature
-25°C to +55°C
Power Consumption
Minimal
Contact Form
1NO+1NC (Auxiliary)
Product Type
MPCB (Motor Protection Circuit Breaker)
Insulation Resistance
>100 M?
Theory
Manual Reset Thermal-Magnetic Circuit Breaker
Usage
Motor Protection
Contact Load
Up to 32A
Operate Time
Instantaneous and Delayed (Adjustable)
Terminal Type
Screw Type
Rated Voltage
690V AC
Supply Terminal
Top & Bottom
Size
Standard (as per Model)
Color
Grey and Black
Dimension (L*W*H)
45mm x 75mm x 85mm (Approx.)
Weight
Approx. 350g
