Mud Pump - FD1600 - Seal, Discharge Manifold - 0-7602-066111 Description
Mud Pump - FD1600 - Seal, Discharge Manifold - 0-7602-066111
MAKE: Mud Pump -
TYPE: FD1600
PART NAME: Seal, Discharge Manifold
PART NO: 0-7602-066111
Discover the FD1600 Mud Pump – a high-performance triplex piston pump widely used in oil & gas drilling operations. Learn about its key features, specifications, and spare parts availability for reliable and efficient drilling fluid circulation.
Key Features of FD1600 Mud Pump
High Power Capacity – Rated at 1600 HP for heavy-duty drilling applications.
Triplex Design – Three-cylinder piston pump ensures smoother discharge and efficient fluid circulation.
High Pressure & Flow – Capable of handling large volumes of drilling mud at high pressures.
Durable Construction – Built with wear-resistant liners, pistons, and valve assemblies for long service life.
Easy Maintenance – Modular components and replaceable spares reduce downtime.
Safety Features – Equipped with relief valves and pressure monitoring for safe operation.
Versatile Application – Suitable for oil & gas rigs, geothermal drilling, and other heavy-duty drilling projects.
Types of Mud Pumps
1. Based on Design
Duplex Mud Pump
Two pistons/liners (double-acting).
Older design, lower efficiency.Still used in some smaller drilling rigs.
Triplex Mud Pump
Three pistons/liners (single-acting).
Smoother discharge, higher efficiency.
Most common type in modern rigs.
Example: FD1600 mud pump (Triplex, 1600 HP).
Quintuplex Mud Pump
Five pistons/liners.
Very smooth flow, reduced pulsation.
Used in ultra-deep drilling and high-pressure operations.
2. Based on Application
Oil & Gas Drilling Mud Pump ? Used on onshore/offshore rigs.
Geothermal Mud Pump ? For high-temperature drilling fluids.
Mining & Construction Mud Pump ? For tunneling, piling, and slurry pumping.
3. Based on Power Rating
Small Capacity Mud Pumps (400–800 HP) – for light drilling.
Medium Capacity Mud Pumps (1000–1600 HP) – like FD1600, standard in many rigs.
Large Capacity Mud Pumps (2000–3000+ HP) – for ultra-deep wells and offshore rigs.
