PERMCO Hydraulic Pumps - Gear Pump M2100A890IDZE10-14 Description
PERMCO Hydraulic Pumps - Gear Pump M2100A890IDZE10-14
BRAND NAME: PERMCO Hydraulic Pumps
MODEL NO: Gear Pump M2100A890IDZE10-14
Alternate Part numbers:
M2100A890IDZE10-14
PEK 8J
Replaces Muncie PK8-2BSBB/PK108-02BSBB
Standard features include:
SAE-B-2&4 bolt mounting flange, SAE-B-spline shaft, both side and rear ports and setup for pump/motor dual rotation applications
A wide range of porting, mounting, and shaft options available
Roller bearing design in a compact, small frame size
Doweled and high-strength cast iron construction
Low weight: 34.5 pounds with a 2” gear, Type II
Flows up to 39 GPM
Working pressure up to 3000 PSI
Speeds up to 2400 RPM
Cubic inch displacements from 1.00 through 4.00
Special ring seals and pressure-balanced wear plates maintain high pump and motor
efficiency throughout all operating ranges
100% factory tested per application specifications
Specifications:
Permco Dual Ported Pump
2/4 Bolt Mount
SAE B - 7/8”-13T Spline Shaft
1” ORB Side & 1” ORB Rear Ports
1” Gear Width
2.00 cu in. per rev
6.5GPM @ 1000 RPM @ 3000 PSI
PERMCO Hydraulic Pumps are American-made, heavy-duty hydraulic pumps built to deliver exceptional performance in high-demand industrial and mobile hydraulic systems. With a reputation for quality, customizability, and durability, PERMCO specializes in gear and vane pumps suitable for high-pressure fluid power applications. Whether it’s powering dump trucks, construction machinery, or factory automation systems, PERMCO pumps are designed to withstand rugged conditions while maintaining long-term reliability and efficiency.
Common Applications:
Dump trucks and vocational vehicles (PTO systems)
Construction machinery (loaders, excavators, mixers)
Agricultural equipment (tractors, sprayers)
Industrial hydraulic presses and machinery
Refuse and sanitation trucks
Marine and offshore hydraulic systems
Snowplows, cranes, and lift systems
Mining and material handling equipment
Hydraulic power units (HPUs)
Key Features:
Rugged Construction
Built with cast iron or aluminum for demanding environments.
High Operating Pressures
Designed to handle pressures up to 4000+ PSI, depending on model.
Wide Range of Displacements
Accommodates various flow and torque requirements.
Custom Configurations Available
Modular design allows easy adaptation to specific systems.
High Efficiency
Tight tolerances and precision machining reduce energy loss.
Reliable in Harsh Conditions
Proven performance in extreme temperature and workload scenarios.
Dual or Multiple Pump Assemblies
Available in tandem and combination units for multi-function use.
Types of PERMCO Pumps:
Gear Pumps – Heavy-duty, high-pressure pumps for industrial and mobile equipment.
Vane Pumps – Low-noise, smooth-flow pumps ideal for industrial applications.
Dump Pumps – PTO-driven pumps designed for dump trucks and refuse vehicles.
Combination Pumps – Dual or triple section pumps for multi-function hydraulic systems.
Reversible Pumps – Allow bi-directional flow; used in winches and lift systems.
Pump-Motor Units – Integrated hydraulic pump and motor assemblies for compact systems.
