PERMCO Hydraulic Pumps - Gear Pump P124 Series Description
PERMCO Hydraulic Pumps - Gear Pump P124 Series
BRAND NAME: PERMCO Hydraulic Pumps
MODEL NO: Gear Pump P124 Series
Permco P124 Series Pump/Motor are a heavy-duty sleeve bushing design in a small frame size. These units are built to withstand working pressure up to 3500 PSI. Internal cubic inch displacements from 0.62” through 2.48”. The 124 series Pump/Motor can handle speeds up to 3000 RPM and produce flows up to 30 GPM. Their housings are doweled to withstand higher pressures and are built using high strength cast iron construction. The internals consist of high strength alloy steel gear and shaft sets. Porting options consist of NPT, ORB, and Split Flange ports. Both single inlet/single outlets and single inlet/dual outlet bearing carriers are available. Also, the pressure balanced wear plates maintain high pump efficiency throughout all operating ranges. The 124 is available as a clutch pump and as a fan motor.
PERMCO Hydraulic Pumps are American-made, heavy-duty hydraulic pumps built to deliver exceptional performance in high-demand industrial and mobile hydraulic systems. With a reputation for quality, customizability, and durability, PERMCO specializes in gear and vane pumps suitable for high-pressure fluid power applications. Whether it’s powering dump trucks, construction machinery, or factory automation systems, PERMCO pumps are designed to withstand rugged conditions while maintaining long-term reliability and efficiency.
Common Applications:
Dump trucks and vocational vehicles (PTO systems)
Construction machinery (loaders, excavators, mixers)
Agricultural equipment (tractors, sprayers)
Industrial hydraulic presses and machinery
Refuse and sanitation trucks
Marine and offshore hydraulic systems
Snowplows, cranes, and lift systems
Mining and material handling equipment
Hydraulic power units (HPUs)
Key Features:
Rugged Construction
Built with cast iron or aluminum for demanding environments.
High Operating Pressures
Designed to handle pressures up to 4000+ PSI, depending on model.
Wide Range of Displacements
Accommodates various flow and torque requirements.
Custom Configurations Available
Modular design allows easy adaptation to specific systems.
High Efficiency
Tight tolerances and precision machining reduce energy loss.
Reliable in Harsh Conditions
Proven performance in extreme temperature and workload scenarios.
Dual or Multiple Pump Assemblies
Available in tandem and combination units for multi-function use.
Types of PERMCO Pumps:
Gear Pumps – Heavy-duty, high-pressure pumps for industrial and mobile equipment.
Vane Pumps – Low-noise, smooth-flow pumps ideal for industrial applications.
Dump Pumps – PTO-driven pumps designed for dump trucks and refuse vehicles.
Combination Pumps – Dual or triple section pumps for multi-function hydraulic systems.
Reversible Pumps – Allow bi-directional flow; used in winches and lift systems.
Pump-Motor Units – Integrated hydraulic pump and motor assemblies for compact systems.
