Rexroth - R902205685 R902071664 R902205694 AA11VLO260LRDS/11R-NSD62N00 - Axial Piston Hydraulic Pump Description
Rexroth - R902205685 R902071664 R902205694 AA11VLO260LRDS/11R-NSD62N00 - Axial Piston Hydraulic Pump
Type: Axial piston variable displacement pump (swashplate design)
Model: A11VLO260LRDS
Series: 11
Displacement: 260 cm³/rev
Nominal Pressure: 350 bar
Maximum Pressure: 400 bar
Control Type: LRDS (load sensing with pressure control)
Mounting Flange: SAE 4-bolt
Rotation: Clockwise (Right), viewed from shaft end
Through-drive: N00 (standard configuration for auxiliary mounting)
Ports: SAE flange ports, case drain ports
Shaft: SAE splined shaft
Speed Range: Up to ~1800–1900 rpm
Weight: Approx. 160 kg
This high-performance axial piston pump from Rexroth delivers exceptional reliability and efficiency for demanding hydraulic applications. Engineered for precise flow control and optimal power transmission, it is ideal for use in industrial machinery and heavy-duty hydraulic systems. Designed to withstand rigorous operating conditions, this variable displacement pump ensures long service life and consistent performance. It is an excellent choice for maintaining and upgrading hydraulic equipment, offering superior durability and efficiency.
