Rexroth - R902220990 R902249609 R902253675 R902235479 A11VO260DR/11R-NPD12N00 - Axial Piston Hydraulic Pump Description
Rexroth - R902220990 R902249609 R902253675 R902235479 A11VO260DR/11R-NPD12N00 - Axial Piston Hydraulic Pump
Type: Axial Piston Variable Hydraulic Pump (Swashplate design)
Model: A11VO260DR/11R-NPD12N00
Series: A11VO260DR
Displacement: 260 cc/rev (variable)
Control: DR (Pressure control)
Nominal Pressure: 350 bar
Maximum Pressure: 400 bar
Rotation: Right (clockwise)
Speed Range: Up to 1800 rpm (application dependent)
Mounting: Flange mounting
Port Connection: SAE standard ports
Fluid: Mineral oil (recommended viscosity 16–36 mm²/s)
Temperature Range: -20°C to +80°C
Weight: Approx. 220 kg
Features:
? Large variable displacement for high-flow hydraulic applications
? Integrated pressure control for energy-efficient, precise operation
? Compact, robust design for heavy-duty industrial and marine hydraulics
? High efficiency and low noise during continuous operation
? Long service life with minimal maintenance
? Suitable for marine, industrial, and heavy mobile machinery systems requiring reliable high-volume hydraulic supply
This high-performance axial piston pump from Rexroth delivers exceptional reliability and efficiency for demanding hydraulic applications. Engineered for precise flow control and optimal power transmission, it is ideal for use in industrial machinery and heavy-duty hydraulic systems. Designed to withstand rigorous operating conditions, this variable displacement pump ensures long service life and consistent performance. It is an excellent choice for maintaining and upgrading hydraulic equipment, offering superior durability and efficiency.
