SIEMENS 7SD6101-5BB99-0BA0/EE Description
SIEMENS 7SD6101-5BB99-0BA0/EESIEMENS 7SD6101-5BB99-0BA0/EE Specification
Protect Feature
Protection for electrical systems
Product Type
Protection relay
Theory
Electrical protection and monitoring
Usage
Electrical system protection and management
Terminal Type
Screw type terminal connections
Supply Terminal
Standard connections for supply terminals
Size
Standard size suitable for panel mounting
Color
Gray
Dimension (L*W*H)
Standard dimensions as per Siemens specifications
Weight
Medium weight suitable for panel mounting exact weight not provided
Warranty
As per Siemens standard warranty policy
About SIEMENS 7SD6101-5BB99-0BA0/EE
LINE-DIFFERENTIAL PROT. RELAY FOR TWO LINE TERMINALS CURRENT TRANSFORMER: IPH = 5A, IE = 5A AUXILIARY VOLTAGE: 110V-250V DC 115V TO 230V AC, BINARY INPUT THRESHOLD 88V, FLUSH-MOUNTING CASE WITH SCREW TERMINALS, 1/3 X 19", 7 BINARY INPUTS, 5 BINARY OUTPUTS, 1 LIVE-STATUS CONTACT REGION WORLD, LANGUAGE ENGLISH (LANGUAGE SELECTABLE) WITHOUT SYSTEM INTERFACE INTERFACE ON REAR SIDE DIGSI 4, ELECTRIC RS232 PROTECTION INTERFACE 1: OPTICAL 820NM, 2 ST-CONNECTORS FO-LENGHT UP TO 1,5KM; FO5 FOR DIRECT CONNECTION OR VIA COMMUNICATION NETWORKS FUNCTION 1: TRIPPING 3-POLE ONLY, WITHOUT AUTO-RECLOSURE WITH EMERGENCY/BACKUP OVERCURRENT-TIME PROTECTION WITHOUT REMOTE COMMANDS/SIGNALS WITHOUT TRANSFORMER EXTENSIONS W/O EXTERNAL GPS-SYNCHRONIZAT. OF DIFFERENTIAL PROTECTION.
