SIEMENS 7SJ6005-5EA00-0DA0/BB

SIEMENS 7SJ6005-5EA00-0DA0/BB Description

SIEMENS 7SJ6005-5EA00-0DA0/BB
SIEMENS 7SJ6005-5EA00-0DA0/BB Specification
Dielectiric Strength
2 kV rms for 1 minute
Protect Feature
Overcurrent, Earth Fault, and optional voltage protection
Working Temperature
-20C to +60C
Contact Material
AgCdO
Contact Resistance
< 100 m
Ambient Temperature
-25C to +70C
Coil Voltage
110/220 V AC
Contact Form
2 Changeover (DPDT)
Mechanical Life
>1 x 10 operations
Coil Power
< 1.2 VA
Power Consumption
< 10 VA
Product Type
SIEMENS 7SJ6005-5EA00-0DA0/BB
Insulation Resistance
> 100 M at 500 V DC
Theory
Electromechanical relay with microprocessor-based protection
Usage
Protection and control device for electrical networks
Contact Load
5 A at 250 V AC
Operate Time
< 15 ms
Terminal Type
Screw terminal
Rated Voltage
220/230 V AC
Supply Terminal
Rear connection
Size
Standard compact relay size
Color
Grey
Dimension (L*W*H)
Approx. 240 x 106 x 220 mm
Weight
Approx. 2.8 kg


About SIEMENS 7SJ6005-5EA00-0DA0/BB
NUMERICAL OVERCURRENT-TIME PROTECTION RELAY SIPROTEC 7SJ600 OVERLOAD PROTECTION, UNBALANCED-LOAD PROTECTION BINARY INPUT VOLTAGE:24 TO 250V WITH ISOLATED RS485 INTERFACE RATED CURRENT: 5A, 50/60HZ RATED AUXILIARY VOLTAGE FOR BUILT-IN CONVERTER DC 24, 48V IN 7XP20 CASE FOR PANEL FLUSH MOUNTING OR FOR CUBICLE MOUNTING OPERATOR LANGUAGE IN ENGLISH, GERMAN, SPANISH AND FRENCH WITHOUT RECLOSURE WITHOUT CONTROL.
