SIEMENS 7SJ6111-5EB00-1FB0/EE Description
SIEMENS 7SJ6111-5EB00-1FB0/EESIEMENS 7SJ6111-5EB00-1FB0/EE Specification
Ambient Temperature
-20C to +70C
Dielectiric Strength
2 kV AC, 50/60 Hz for 1 min
Working Temperature
-20C to +60C
Contact Material
Silver Alloy
Protect Feature
Overcurrent, Earth Fault, Short Circuit
Coil Voltage
110-240V AC/DC
Contact Resistance
<100 m
Power Consumption
Approx. 15 W
Mechanical Life
>10 Million Operations
Contact Form
SPDT/DPDT
Coil Power
<3.5 W
Product Type
Numerical Protection Relay
Insulation Resistance
> 100 M at 500 V DC
Theory
Digital Microprocessor-Based Relay
Usage
Feeder Protection Relay
Contact Load
5A at 250V AC/30V DC
Operate Time
Approx. 15-25 ms
Terminal Type
Screw Terminal
Rated Voltage
110-240 V AC/DC
Supply Terminal
Rear Terminal Block
Size
Standard Panel Mount
Color
Grey/Black
Dimension (L*W*H)
Approx. 193 x 96 x 211 mm
Weight
Approx. 2.5 kg
About SIEMENS 7SJ6111-5EB00-1FB0/EE
MULTIFUNCTION PROTECTIVE RELAY WITH BACKLIT TEXT DISPLAY, 4 X 20 CHARACTERS, 7 PROGRAMMABLE LED, CASE 1/3 19", 8BI, 8BO, 1 WATCHDOG CONTACT PHASE CURRENT TRANSFORMER 1A SUPPLY VOLTAGE:DC 110V TO 250V, AC 115V TO 230V, TRIGG.LEVEL BINARY INPUT DC 88V FLUSH MOUNTING CASE, SCREW TERMINALS (DIRECT WIRING/RING LUGS) LANGUAGE ENGLISH, 50/60HZ, IEC/ANSI, REGION WORLD, (LANGUAGE CHANGEABLE) NO SYSTEM PORT WITHOUT DIGSI 4/MODEM PORT METERING: FAULT RECORDING FUNCTIONALITY: TOC+ MOTOR PHASE OVERCURRENT (50/51): I>,I>>,IP,REVERSE INTERLOCKING, INDEPENDENT OF PHASE ROTATION, GROUND OVERCURRENT (50N/51N): IE>, IE>>,IEP, OVERLOAD PROTECTION WITH 2 TIME CONSTANTS (49), TRIP CIRCUIT SUPERVISION (74TC) BREAKER FAILURE PROTECT.(50BF), COLD LOAD PICKUP, INRUSH BLOCKING, NEGATIVE SEQUENCE (46) LOCK OUT (86) MOTOR PROTECTION: UNDERCURRENT (37), NEGATIVE SEQUENCE (46), START UP SUPERVERSION (48), START UP BLOCK./LOCKOUT (66/86) WITHOUT AUTO-RECLOSURE
