SIEMENS AIR CIRCUIT BREAKER

SIEMENS AIR CIRCUIT BREAKER Description

SIEMENS AIR CIRCUIT BREAKER
SIEMENS AIR CIRCUIT BREAKER Specification
Phase
Three Phase
Breaking Capacity
Up to 100kA
Mechanical Life
20,000 Operations
Rated Short Circuit Breaking Current
Up to 100kA
Rated Short Circuit Making Current
Up to 220kA peak
Product Type
Air Circuit Breaker
Installation Options
Fixed or Draw-out type
Function
Overcurrent protection, Short-circuit protection, Switch disconnector
Poles Number
3/4 Poles
Rated Voltage
AC 690V
Rated Current
630A to 6300A
Rated Frequency
50/60 Hz
Curves
Standard and Special Trip Curves
Temperature Protection
Inbuilt Thermal Protection
Weight
Approximately 60-100 kg, depending on frame size
Color
Siemens Standard Grey
