Number of inputs and outputsNumber of analogue outputs: 2Measuring range5…300 l/min0.3…18 m3/h80…4755 gph1.3…79.3 gpmProcess connectionthreaded connection G 2 external thread DN50 flat seal

Special featureGold-plated contactsApplicationempty pipe detection; for industrial applicationsInstallationconnection to pipe by means of an adapterMediaconductive liquids; water; hydrous mediaNote on mediaconductivity: ?? 20 ??S/cmviscosity: < 70 mm2/s (40 ??C)Medium temperature-10…90 ??C14…194 ??FPressure rating [bar]16Pressure rating [MPa]1.6Pressure rating [psi]232MAWP (for applications according to CRN) [bar]16

Operating voltage [V]18…32 DC; (to SELV/PELV)Current consumption [mA]< 150
