Yuken - CPDG-10-20-60 CPDG-06-E-20-50 CPDG-03-50-50 - Hydraulic Valves Description
Yuken - CPDG-10-20-60 CPDG-06-E-20-50 CPDG-03-50-50 - Hydraulic Valves
Brand Name: Yuken Hydraulic Valves
Model No: CPDG-10-20-60 CPDG-06-E-20-50 CPDG-03-50-50
Yuken Hydraulic Valves are high-performance control components used in hydraulic systems to regulate direction, pressure, and flow of hydraulic fluid. Engineered for reliability, precision, and efficiency, Yuken valves are widely used in industrial automation, mobile machinery, and heavy-duty equipment. Available in a variety of configurations including directional control, pressure control, and flow control valves, Yuken valves ensure optimal performance in complex hydraulic circuits.
Key Features:
High Precision Control
Ensures accurate regulation of pressure, flow, and direction.
Modular Design
Stackable valve design allows compact system layout.
Wide Product Range
Includes solenoid-operated, pilot-operated, modular, and proportional valves.
Durable Construction
Built with high-quality materials for long service life under harsh conditions.
Smooth Operation
Fast response and low pressure drop ensure stable hydraulic performance.
Standardized Mounting
Easy installation with international sub-plate and manifold standards.
Energy-Efficient Options
Valves available with pressure and flow optimization to reduce power consumption.
Common Points / Applications:
Industrial machinery
Plastic injection molding machines
Metal forming presses
Hydraulic power packs
Construction equipment
Machine tools
Marine and offshore systems
Agricultural machinery
Types of Yuken Hydraulic Valves
1. Directional Control Valves (DCVs)
Control the direction of hydraulic fluid flow to actuators (cylinders or motors).
Solenoid Operated Directional Valves
Example: DSG-01, DSG-03
Function: Electrically controls flow direction
Pilot Operated Directional Valves
Example: DSHG-04, DSHG-06
Function: Controls large flow via pilot pressure
Manually Operated Valves
Example: MRP-01
Function: Hand lever-operated for simple control
2. Pressure Control Valves
Regulate system pressure and protect against overpressure.
Relief Valves
Example: BSG Series, BSR Series
Function: Limits max pressure to protect system
Pressure Reducing Valves
Example: DR, DT, DRT Series
Function: Maintains reduced pressure in part of circuit
Sequence Valves
Example: SD Series
Function: Operates actuators in a preset sequence
Unloading Valves
Example: BUV Series
Function: Diverts flow from pump when not needed
3. Flow Control Valves
Regulate the speed of actuators by controlling flow rate.
Throttle Valves
Example: MTC, MTF Series
Function: Simple restriction-based flow control
Pressure-Compensated Flow Control Valves
Example: MRV, MFB Series
Function: Maintains constant flow regardless of load pressure
4. Modular Valves (Stack Type)
Compact, stackable valves for system integration.
Modular Relief, Flow, Check, and Throttle Valves
Example: MRP, MPA, MPW, MSA Series
Function: Compact control for direction, pressure, and flow
5. Proportional Electro-Hydraulic Valves
Electronically control pressure and flow in real time.
Proportional Pressure Control Valves
Example: EBG Series
Function: Variable pressure based on electrical input
Proportional Directional Valves
Example: EDSG Series
Function: Variable flow and direction electronically
6. Check Valves
Allow flow in one direction only; prevent backflow.
Inline Check Valves
Example: CV Series
Simple non-return valves
Pilot Operated Check Valves
Example: OC Series
Allow reverse flow when pilot pressure is applied
